IKA Works Vacuum Control Valve Package, Manual

Allows for adjusting the set vacuum value on the manual manometer.

VC 10.400 stand not included in the scope of delivery, available as accessory (ID no. 0035001735).

Connection diameter suction side [mm]: 8

Connection diameter pressure side [mm]: 8

Input pressure [mbar]: 1 - 1050

Boiling point detection: no

Solvent library: no

Two-point control: no

Analog speed vacuum control: no

Pressure unit / scale: mbar

Vacuum sensor: no

Control range [mbar]: 1 - 1050

Resolution pressure [mbar]: 50

Measurement uncertainty [mbar]: 25

Medium temperature (gas) [°C]: 5 - 40

Vacuum valve: no

Venting valve: yes

Material in contact with medium: Al2O3, PP, stainless steel

Housing material: PP

Fastening: stand / clamp

Dimensions (W x H x D) [mm]: 65 x 255 x 140

Weight [kg]: 0.6

Permissible relative humidity [%]: 80

Protection class according to DIN EN 60529: IP 65
