Globe Scientific Euromex Inverted trinocular micros.
List Price
$4,527.00
Your Price
$4,527.00
Globe Scientific Inverted trinocular microscope with mech, stage 10/20/40x, 5W LED & w/transpor. box - GLO
GROUP SKU:
GLO-EOX-2053-PLPH
Oxion Inverso: Unleash the Power of Inverted Microscopy for Life Science Applications
The Oxion Inverso series of inverted microscopes brings a new level of precision and versatility to the field of life science research. Specifically designed for phase contrast applications, these advanced instruments allow you to observe living organisms and tissue cultures with exceptional clarity and detail in cell culture dishes and flasks.
Features:
- Phase Contrast Capability: The Oxion Inverso inverted microscopes are equipped with specific objectives that compensate for the 1.2 mm thick bottoms of petri dishes or culture dishes. This ensures optimal imaging and contrast, enabling you to visualize and study your samples with accuracy.
- Versatile Life Science Applications: Ideal for a wide range of life science applications, these microscopes provide a reliable platform for observing living organisms and tissue cultures. Whether youre studying cell behavior, conducting live cell imaging, or examining tissue samples, the Oxion Inverso series delivers exceptional performance.
- Revolving Quintuple Nosepiece: Easily switch between multiple objective lenses with the revolving quintuple nosepiece. This feature allows you to quickly adjust the magnification and focal point to suit your specific research requirements.
- Fluorescence Capabilities: The inclusion of a 100 W mercury vapor lamp enables fluorescence imaging, opening up new possibilities for studying fluorescence-labeled samples and exploring molecular interactions in live cells or tissues.
- Long Working Distance IOS: The Oxion Inverso microscopes feature long working distance Infinity-Corrected Objective Systems (IOS). This design allows you to observe samples even when using containers with a significant distance between the objective lens and the specimen, such as petri dishes or culture flasks.
- 5 W LED Transmitted Illumination: Enjoy uniform and bright illumination with the energy-efficient 5 W LED transmitted illumination system. This lighting solution provides excellent visibility and allows you to capture high-quality images.
Oxion Inverso
| EOX-2053-PLPH |
Head | Trinocular 45º inclined. 54-75mm interpupillar. Diopter adjustment on left eye tube |
Eyepiece | HWF plan 10x/22mm |
Nosepiece | Quintuple |
Objective | Plan phase 10x/0.25, 20x/0.40, 40x/0.60 IOS objectives |
Stage | 250x230mm. XY: 120x78mm. Includes: stage extension. Metal insert Ø65mm stage. Metal insert 76x26mm for slides |
Condenser | A.N. 0,30 with iris diaphragm. Slider with PH rings for 4x/10 and 20x/40x objectives |
Illumination | 5W NeoLed™ |
EYEPIECES
- Pair of DIN HWF plan 10x/22mm eyepieces
HEAD
- Trinocular 45° inclined tubes with extended low and high positions for eyepieces
- One diopter adjustment on left eyepiece
- Interpupillary distance of 54 to 75mm
- Trinocular head with 100-0 % and 0-100 % positions
NOSEPIECE
- Revolving quintuple nosepiece on ball-bearings
OBJECTIVES FOR PHASE CONTRAST
- Infinity color corrected long working distance plan phase 10x/0.25, 20x/0.40, 40x/0.60 IOS objectives
All objectives corrected for 1.2mm thickness.
All optics are anti-fungus treated and anti-reflection coated for maximum light throughput
STAGE
Stage 250 x 230mm equipped with a coaxial mechanical 120 x 78mm X-Y stage, delivered with:
- metallic insert for Ø 35mm cell culture dish dishes
- 76 x 26mm slide holder
- glass insert with hole
CONDENSER
- A. 0.30 condenser with iris diaphragm. Working distance 72mm
- The model for the phase contrast OX.2053- PLPH is delivered with a slider with 4x/10x and 20x/40x pre-centered phase rings
FOCUSING ADJUSTMENT
- Coaxial 25mm coarse and fine adjustments, 2μm precision and with friction adjustment
ILLUMINATION
- Transmitted 5W LED Intensity adjustable with internal 100-240V power supply. Fuse holder 3.15 A / 250V.
FILTERS FOR PHASE CONTRAST MODELS
- Interference filter 550nm green and blue filter, 45mm diameter
PACKAGE CONTENT
- Supplied with power cord, dust cover and user manual
- Phase contrast models are supplied with green filter and alignment telescope
- Microscope supplied in a transport case
Item # | Description |
EOX-2053-PLPH | Inverted Microscope, Biological, Phase Contrast, 10x/22mm Eyepieces, LWD Plan Phase 10/20/40x Objectives, Mechanical Stage (250x230mm with Coaxial 120x78mm X-Y Stage, including metallic insert for Ø 35 mm cell culture dish dishes, 76 x 26mm slide holder and glass insert with hole) |
