Globe Scientific Euromex CMEX-5 Pro, 5.0 MP dig.USBdig.
List Price
$651.00
Your Price
$651.00
Globe Scientific CMEX-5 Pro, 5.0 MP digital USB-3 camera , with 1/2.5 inch CMOS sensor - GLO
GROUP SKU:
GLO-EDC-5000-PRO
The high-speed USB-3 cameras with ImageFocus Alpha capture and analysis software are the perfect solutions for today’s educational, laboratory and industrial microscopy needs. The cameras are suitable for life science, material science and stereo microscopes.
The CMEX-5 Pro, CMEX-10 Pro and CMEX-18 Pro cameras are equipped with relatively 5.1, 10 or 18MP CMOS sensors with 12-bits grayscale conversion and a 24-bits color rendering. These cameras are equipped with a USB- 3 data interface enabling fast frame rates.
Besides taking images and videos, the ImageFocus Alpha software allows measurements on still and live images and to perform annotations on captured images. Compatible with Windows 10 and 11, both 32- and 64-bits configurations. A 2GB RAM 2.8GHz computer and 17-inch display is recommended as a minimum requirement.
FEATURES
- High speed cameras
- ADC 12-bits, color depth 24-bits
- Excellent software
- USB 3.0 interface (USB 2.0 compatible)
- 3.1 to 18MP CMOS sensors
- Great color reproduction
- Low signal/noise ratio
CMEX Pro High-Speed Cameras
| EDC-5000-PRO | EDC-10000-PRO | EDC-18000-PRO |
Pixels (MP) | 5.1 | 10 | 18 |
Sensor | 1/2,5” CMOS | ||
Pixel size (μm) | 2.2 x 2.2 | 1.67 x 1.67 | 1.25 x 1.25 |
Exposure time | 0.1ms ~ 2000ms | 0.1ms ~ 2000ms | 0.1ms ~ 2000ms |
Resolutions | 2560 x 1922 1280 x 960 640 x 480 | 3584 x 2746 1792 x 1372 | 4912 x 3684 2456 x 1842 1228 x 922 |
Max. frames (p/sec) | 14 39 100 | 8 25 | 6 18 32 |
Grayscale conversion | 12-bits | ||
Color rendering | 24-bits | ||
Signal/ Noise (db) | 39 | 35.5 | 42 |
Dynamic (db) | 68 | 63.5 | 65 |
Sensitivity V/lux-sec | 1.76 | 0.31 | 1.3 |
TECHNICAL SPECIFICATIONS
| EDC-5000-PRO | EDC-10000-PRO | EDC-18000-PRO |
Sensor | CMOS 1/2.5 inch | ||
Pixels | 2560 x 1922 pixels, 5.1MP | 3584 x 2746 pixels, 10.0MP | 4912 x 3684 pixels, 18.0MP |
Scan mode | Progressive, rolling shutter | ||
Pixel size | 2.2μm x 2.2μm | 1.67μm x 1.67μm | 1.25μm x 1.25μm |
Filter | RGB | ||
Mount | C-mount | ||
Max fps | Up to 14 frames per second (2560x1922 pixels) | Up to 8 frames per second (3584 x 2746 pixels) | Up to 6 frames per second (4912 x 3684 pixels) |
Exposure | Automatic or manual | ||
White Balance | Automatic or manual | ||
Dynamic range | 68dB | 63.5db | 65db |
S/N max | 39dB | 35.5db | 42db |
Sensibility V/lux-sec | 1.76 | 0.31 | 1.3 |
Data interface | USB 3.0 high speed | USB 3.0 high speed 80Mb/s | USB 3.0 high speed 80Mb/s |
Operation | -10~50°C, 30-80 % humidity | 0 – 50°C, 30-80 % humidity | 0 – 50°C, 30-80 % humidity |
Storage temperature | -20 to 60° Celsius | ||
Power supply | 5VDC over PC USB Port | ||
Housing | Integrated CNC aluminum alloy | ||
Supplied with | 0.5x objective with C-mount, USB 3 cable, 30 and 30.5mm adapters for stereomicroscopes, 76x24mm calibration slide (1mm/100), carton box | ||
Software | ImageFocus Alpha capture and measuring software for Win 10/11 (32- and 64-bit configurations). A Mac OS version is available | ||
PC requirements | Compatible with Intel Core 2, 2.8GHZ or higher, 2GB, USB-3 high-speed | ||
Item # | Description |
EDC-5000-PRO | CMEX-5 Pro, 5.0MP digital USB-3 camera with 1/2.5-inch CMOS sensor |
EDC-10000-PRO | CMEX-10 Pro, 10MP digital USB-3 camera with 1/2.3-inch CMOS sensor |
EDC-18000-PRO | CMEX-18 Pro, 18.0MP digital USB-3 camera with 1/2.3-inch CMOS sensor |
| SKU | GLO-EDC-5000-PRO |
|---|---|
| Featured | No |
| Supplier Part Number | EDC-5000-PRO |
| UM | EA |
| UNSPSC | 41111700 |
| Manufacturer Name | Globe Scientific Inc |
| CountryOfOrigin | China |
| ProductLine | GLO |
| Qty | 1 |
| MinOrderQty | 1 |
| Width | 5.31 |
| Depth | 8.07 |
| Height | 4.92 |
| Weight | 1.540000 |
| Lead Time | 7 |
| Hazardous | N |
| Energy Star | No |
| Green | No |
| Controlled | N |
