IKA Works Heating Bath Circulator, Icc Basic Pro 20 Open Model, 20l, 340 H x 145 W x 200mm D

IKA facilitates the configuration of your temperature control system by offering “ready for connection“ packages with all necessary accessories.

Package includes

• ICC basic Compact Immersion Circulator
• IB 20 pro Stainless steel bath (size L)
• BL.ICC Large bridge

total: 354 x 641 x 388 mm

bath opening: 255 x 309 mm *

max. bath opening:  292 x 325 mm **

Immersion depth. 85 mm–125 mm

*Dimensions to set plate at the bottom of bath.

** Maximum bath opening dimensions at the upper edge of the bath

Max. temperature in the stainless steel bath (“pro” series): 150 °C

Technical data relates to the temperature control instrument included in the package

Appliance type: Compact immersion circulators

Class designation acc. DIN 12876: III

Identification according to DIN 12876: FL

Heat output [W]: 2000

Working temperature [°C]: room temp. +10K @1000rpm - 150

Operating temperature min. (with external cooling) [°C]: -20

Temperature display: yes

Temperature control: PID

Working temperature sensor: PT 100

Safety temperature sensor: PT1000

Working temperature display: LED

Safety temperature display: LED

Temperature stability DIN 12876 [K]: ±0.02

Display resolution [K]: 0.1

Display for operation with ext. sensor: yes

Set temperature resolution [K]: ±0.1

Warning function optical : yes

Warning function acoustic : yes

Warning function excess temperature : yes

Warning function insufficient temperature : no

Adjustable safety circuit [°C]: 0 - 160

Sub-level protection: yes

Over-level protection : yes

Pump type: Pressure- / suction pump

Pump capacity adjustable : yes

Pump pressure max. (0 liters discharge flow) [bar]: 0.3

Pressure pump (suction side) (0 liter flow) [bar]: 0.2

Flow rate max. (0 bar back pressure) [l/min]: 18

Bath depth min. [mm]: 150

Calibration option: yes

Appliance fastener: clamp

Technical data complies with the standard: DIN 12876

Permissible ON time [%]: 100

Dimensions (W x H x D) [mm]: 145 x 340 x 200

Weight [kg]: 16.27

Permissible ambient temperature [°C]: 5 - 40

Permissible relative humidity [%]: 80

Protection class according to DIN EN 60529: IP 21

RS 232 interface: yes

USB interface: Micro-USB

Voltage [V]: 230

Frequency [Hz]: 50/60

Power input [W]: 2100
