Simplify your workflow—tool-free design makes it fast and easy for anyone to make consistent, quality connections.
Extend air canister and valve lifetime—no wrenches mean no overtightening or cross-threading damage.
Stand-alone or supporting roles—use alone or pair with a bellows/diaphragm valve for the ultimate in sample security and convenience.
Check status at a glance—if the parts are connected, the valve is open; if they’re apart, it’s closed. (Open-position valves also available.*)
Standard compression or tube end fittings accommodate a wide variety of air canisters and related devices.
Leak-free performance—each and every valve is helium leak tested to 1x10-6 mL/sec.
Compatible with Entech Micro-QT valves.
Note: A RAVEqc valve bracket is required for use with Restek 1, 3, 6, and 15 L air sampling canisters when using the compression fitting mounted directly on the 1/4" canister tube stub. This bracket is not needed when using Restek miniature canisters or Entech canisters.
Description
RAVEqc Quick-Connect air valves are a fast, easy, tool-free way to attach air canisters to the wide variety of devices used to sample and analyze air samples.
Restek Air Valve Excellence (RAVE) is a great family of products that upgrade your existing air canisters to improve reliability and performance.
Made in the U.S.A.
Valve
Max Flow @ 29" Hg (mL/min)**
6 L Grab Sample Time (sec)
RAVEqc quick-connect air valve
2500
240
RAVEqc high-flow quick-connect air valve
3850
120
RAVE diaphragm valve
40,000
10
** Flow rates calculated on a 1/4" platform.
* Open-position option available to prevent vacuum/pressure from being trapped by the valve when desired (e.g., when using a vacuum/pressure gauge). High flow facilitates use with canister-cleaning ovens.
Catalog No.
27347
Product Name
RAVEqc Quick-Connect Female Valve to 1/4" Male Tube Fitting
